BASAL IMPLANT KIT

Description

SURGICAL KIT
The surgical kit from mono implants (Switzerland) comprises of:



A – 8 DRILLS
The surgical drills are made of titanium. The drills are colour coded as per core diameter of drill. Yellow (2.0mm), (black) 2.5mm, (red) 3mm (white) 3.5mm (fig 6.6).
Each drill is laser marked at 6mm,8mm,10mm 12mm, 14 mm ,17 mm,20 mm 23mm and 26mm. Each drill is available in 2 lengths i.e. short drill (20 mm), long drill (30mm).



B – EXPANSION SCREWS/BONE TAPS
Expansion screws are in short and long lengths. The diameters of bone taps are 3.0mm,3.2mm, 3.7mm,4.1mm and 4.7mm.



C – DRIVERS
Drivers are available in 2 diameters corresponding to abutment heads i.e. large diameter and small diameter. They are available in 3 lengths – extra short, short, and long for convenience of use during operations.



D – ADVANCED TORQUE RATCHET



E. HANDGRIPS
Handgrips allow the operator to place the implants manually. This allows better control during implant placement and provided a tactile perception of torque received during implant placement. Handgrips are available in two diameters large and regular for placement of large head and regular head implants.



F. PTERYGOID TAP
This instrument is specifically constructed to place the pterygoid implant. It allows manual scouting of pterygoid area before starting the osteotomy with a drill

Basal Implants Surgical Kit Explained

Basal Implants Surgical Kit Explained

FREQUENTLY ASKED QUESTIONS

Which company implant kit to be used?

The company’s name is monoimplants it is a Switzerland based company.

How many components does the kit contain?

The kit has 28 components. This single kit is sufficient for doing all the basal implant cases no other additional armamentarium is required. This is a onetime investment.

Can this kit be used for bcs, kos and pterygoid implants?

All types of implants can be placed with this single kit

What is the type of torque wrench?

The kit contains advanced toque ratchet.

Is the kit autoclavable?

All the components come in an autoclavable box. It can be cleaned sterilised and autoclaved after every use.
